Name: EZ SPOT UR Skid Steer Double Pole Claw
Brand: EZ SPOT UR
SKU: EZ-0008
Price: 3620.0 USD
Availability: InStock

EZ SPOT UR Skid Steer Double Pole Claw

See more by EZ SPOT UR

2 Videos

Optimal Flow Range 20 - 30 GPM

Sets Poles Up To 32' Long

Load Capacity 1,100 lbs

Commonly Used For

Light Pole Installation

Utility Pole Removal and Replacement

Storm Clean-Up

EZ SPOT UR Skid Steer Double Pole Claw

See more by EZ SPOT UR

2 Videos

Limited time deal

$3,620

List Price:

In Stock

Delivery By Wednesday, November 05

SKU: EZ-0008

Weight: 218.0 lb

Attachment Base Jaw Inserts Wiring Harness

Frequently Bought With

Product Overview

Transform your operations with the best-kept secret on the jobsite: the EZ SPOT UR Double Pole Claw Attachment. Engineered for discerning professionals, this premium tool effortlessly handles and places poles up to 32 feet and 1,100 lbs. Unlock massive cost-savings and all-terrain pole-setting capabilities for your crew. EZ SPOT UR -- on the front lines of innovation.

🏆 High-Performance Equipment
⏳ Saves Hours Of Work👇 Specifications Below

Specifications

Equipment Specifications

Two 2" x 6" clamp cylinders confidently open and close the jaws of the attachment while ensuring a solid grip throughout.

Each clamp cylinder has a breakout force of 9,425 lbs.

Upper jaws are 7.5" wide and bottom jaw is 23" wide.

The two jaws operate independently and close in sequence for safety and security.

Comes standard with rubber lining on the jaws to protect the pole and allow use on any type of pole.

Comes complete with hoses, flush faced couplers, spring hose mount and wiring harness.

Can be adapted to fit excavators, wheel loaders, telehandlers and backhoes*.

*Requires specialty bolt-on mount.

Technical Documents

Open EZ-0008_Double_Pole_Claw_Specification_Page

What's Included

What's Included:

If "No Attachment Base" is selected at time of order:

EZ SPOT UR Double Pole Claw Skid Steer Grapple Attachment Head Only -- 2" Hex Output Shaft to mount to an existing EZ SPOT UR Attachment Base
Hydraulic Hoses, Couplers Included -- Used to connect the grapple head to an existing Attachment Base
EZ SPOT UR Double Pole Claw Operating Manual
Optional Jaw Inserts Pre-Installed on EZ SPOT UR Double Pole Claw if selected at time of order

If "Fixed Non-Rotating Attachment Base" is selected at time of order:

EZ SPOT UR Double Pole Claw Skid Steer Grapple Attachment Head
Fixed Non-Rotating Attachment Base w/ Quick-Tach Included
Hydraulic Hoses, Couplers Included: Hose length and couplers matched to your vehicle
EZ SPOT UR Double Pole Claw Operating Manual
Optional Jaw Inserts Pre-Installed on EZ SPOT UR Double Pole Claw if selected at time of order

If "Double Cylinder Rotating Attachment Base" is selected at time of order:

EZ SPOT UR Double Pole Claw Skid Steer Grapple Attachment Head
Double Cylinder Rotating Attachment Base w/ Quick-Tach Included
Hydraulic Hoses, Couplers Included: Hose length and couplers matched to your vehicle
EZ SPOT UR Wire Harness matched to your vehicle, includes Wire Tool for Pin Adjustment.
EZ SPOT UR Double Pole Claw Operating Manual & Wiring Instructions
Optional Jaw Inserts Pre-Installed on EZ SPOT UR Double Pole Claw if selected at time of order

All of the above configurations also include:

EZ SPOT UR 12-Month Manufacturer Warranty
Attachments King Vehicle Compatibility Guarantee
BONUS! 30-Day Dedicated 1-on-1 Support for Attachment Install & Use from an Attachments King Expert
