Name: Digga "ALT" 2-Speed Piling Anchor Drive For Low Pressure Excavators
Brand: Digga
SKU: 7ALT-11
Price: 10800.0 USD
Availability: InStock

Digga "ALT" 2-Speed Piling Anchor Drive For Low Pressure Excavators

See more by Digga

2 Videos

Max Pressure 3000 PSI @ 27 GPM

Output Shaft 2.5" Hex

Included Valves Pressure Relief and Energy Control

Commonly Used For

Residential Foundation Construction

Solar Panel Installation

Light Pole Installation

Digga "ALT" 2-Speed Piling Anchor Drive For Low Pressure Excavators

See more by Digga

2 Videos

Limited time deal

$10,800

List Price:

Built To Order

Delivery By Saturday, November 15

SKU: 7ALT-11

Weight: 400.0 lb

Max Torque Includes Halo

Frequently Bought With

Product Overview

Add a new world of unparalleled reliability and versatility to your jobs with Digga's "ALT" series of 2-speed piling anchor drives for low pressure 3000 PSI machines. This drive is designed and manufactured in-house to deliver increased power for large piles at high power, and optimal efficiency at low RPM - selectable with the flip of a switch. Digga's standard pressure relief valve (PRV) and energy control valve (ECV) protect your gear from wear and tear caused by pile kick-back. Like having 2 drives in one, this drive opens up a whole new array of jobs for you and your team.

Note: Case drain is required for all 2-speed drives. 2-speed controller unit kit, hoses, and mount are sold separately.

✔ Perfect for 3000 PSI Machines
✔ Integrated Pressure Relief Valve
✔ ECV to Prevent Rapid Decompression

Specifications

ALT Series Specifications

	7ALT	9ALT	12ALT	13ALT	16ALT	20ALT	25ALT
Nominal Torque (FT LBS)	7,333	10,310	12,705	14,098	17,739	21,452	26,991
Max Pressure - Do Not Exceed	3000psi @ 27gpm	3000psi @ 27gpm	3000psi @ 27gpm	3000psi @ 33gpm	3000psi @ 33gpm	3000psi @ 39gpm	3000psi @ 39gpm
Max Flow - Do Not Exceed	53gpm @1800psi	53gpm @1950psi	53gpm @1950psi	53gpm @ 2200psi	53gpm @ 2200psi	53gpm @ 2600psi	53gpm @ 2600psi
Max Horse Power	55	60	60	67	67	80	80
Pressure Relief Valve	Included	Included	Included	Included	Included	Included	Included
Energy Control Valve	Included	Included	Included	Included	Included	Included	Included
Standard Output Shaft	2.5” Hex	2.5” Hex	2.5” Hex	3” Hex	3” Hex	100mm Square	100mm Square
Weight (lbs)	400	440	485	485	485	675	675
Overall Length (in)	37.9”	39.3”	39.3”	42.1”	42.1”	49.5”	49.5”
Diameter (in)	13.4”	13.4”	13.4”	13.4”	13.4”	14”	14”

Technical Documents

Open 7ADT

Open 12ADT

Open 20ADT_25ADT_30ADT

Open 13ADT_16ADT

What's Included

Digga ALT Anchor Drive

Digga "ALT" 2-Speed Low Pressure Piling Anchor Drive
Fitted with Digga-designed Eaton bell motors with an integrated pressure relief valve and input housing, the industry-leading design allows for optimal performance returns when installing both large and small piles.

Over 30 years of design and development have perfected this drive, enabling maximum performance in a sleek, compact profile.

Fitted with Digga-designed Eaton bell motors including an integrated pressure relief valve that prevents damage from pile kick-back.
2-speed capability is like having two drives in one, allowing you to install larger piles with ease and smaller piles with increased efficiency at the flick of a switch.
Compatible with machines with 3000 PSI, see high-pressure "ADT" series for machines with 3500 PSI.

Digga anchor drives are backed by industry-leading warranties and local factory support.

Also included with this purchase:

Digga ALT Anchor Drive Unit Operating Manual
Digga 3-Year Gearbox Warranty
Digga 2-Year Motor Warranty
Digga 12-Month Manufacturer Warranty
Attachments King Vehicle Compatibility Guarantee
BONUS! 30-Day Dedicated 1-on-1 Support for Attachment Install & Use from an Attachments King Expert

Note: All 2-speed drives come fitted with a 10ft electrical connection. 2-speed controller, hoses, and mount sold separately.

Shipping & Returns

We offer FREE 2-5 day shipping (LTL Freight and Residential) for all Digga attachments. Products will ship out in 1-3 business days and tracking information will be provided.

30-DAY NO HASSLE REFUNDS AND RETURNS

If there's an issue with your product, we make refunds and returns quick and easy. To contact us, email sales@attachmentsking.com.

More information on refunds and returns can be found here.

Warranty

All Digga attachments carry a 12-month warranty against defects in material or workmanship.

Refer to manufacturer's manual for full warranty details.

Warranty Guidelines:
-Warranties are subject to approval from Digga
-Warranty repairs are not to be carried out without pre-approval from Digga
-Maintenance must be carried out as per the operator's manual to maintain warranty
-Do not disassemble a Digga product before getting approval and instructions from Digga
-Ensure attachments are utilized only for their intended use as outlined by Digga

The following warranty applies to the specific components of the below models:

MDS / DSS / DDS Drives - Drilling
5 year gearbox | 3 year motor | 1 year manufacturer
INCLUSIVITY / USAGE
Used for drilling. If a DSS or DSS drive is used for anchoring, an ECV (Energy Control Valve) must be fitted for the warranty to be valid.

ADS / ALS Drives - Anchor Application (ECV)
3 year gearbox | 2 year motor | 1 year manufacturer
INCLUSIVITY / USAGE
Anchor application - 5ADL-30ADL - ECV fitted (Energy Control Valve).

DSS / DDS / DLS Drives - Anchor Application
2 year gearbox | 1 year motor | 1 year manufacturer
INCLUSIVITY / USAGE
Anchor application up to 12,000lbs - ECV not fitted (Energy Control Valve).

Bigfoot / Hydrive Trenchers
3 year gearbox | 2 year motor | 1 year manufacturer
INCLUSIVITY / USAGE
Trenching applications.
