Elevate your drilling game with Digga's 4DDS High-Flow Auger Package. Tailored for industry professionals, the exclusive auger unit minimizes downtime and maximizes drilling depth. With 30+ years of unmatched expertise, Digga guarantees performance and quality like no other. Set yourself apart with next-gen auger technology. Note: Auger Bit is sold separately.
| SPECIFICATION | 4DDS |
|---|---|
| TORQUE (FT-LBS @ 3000 PSI) | 3,583 |
| MAX TORQUE FT-LBS @ 3500 PSI | 4,180 |
| RECOMMENDED FLOW (GPM) | 10-36 |
| MOTOR TYPE | EATON |
| MAX PRESSURE - | DO NOT EXCEED 3500 PSI @ 27 GPM |
| MAX FLOW - | DO NOT EXCEED 42 GPM @ 3100 PSI |
| MAX HORSE POWER | 55 |
| PRESSURE RELIEF VALVE | INCLUDED |
| STANDARD OUTPUT SHAFT | 2 HEX |
| HALO | OPTIONAL |
| RECOMMENDED AUGER | A4 / RC4 |
| MAX DRILLING DIAMETER (CLAY / SHALE)* | 24 |
| MAX DRILLING DIAMETER (EARTH)* | 40 |
| WEIGHT (LBS) | 180 |
| OVERALL LENGTH (IN) | 29 |
| DIAMETER (IN) | 9.4 |
| (*) Max/min drilling diameter (DIA) dependent on ground conditions. Guide is a recommendation only. |
Open Drilling--Highflow_Skid_Steers
Digga 4DDS High Flow Auger Drive Unit
Fitted with Digga-designed Eaton bell motors with an integrated pressure relief valve and input housing, the innovative design allows the gearbox to go down the hole to maximize drilling depth without extensions.
Over 30 years of design and development have perfected this drive unit, enabling maximum performance in a sleek, ergonomic profile.
- Digga-designed Eaton motor eliminates the need for bulky valve blocks while reducing many potential leak points
- 2-piece shaft design ensures maximum side load ratings without increasing load on bearings
- Compatible with vehicles that put out 10-36 GPM of hydraulic flow at up to 3500 PSI
- 2" Hex Output Shaft matches industry-standard Auger Bits
- Compact, high-torque Digga-manufactured gearbox generates a whopping 4,180 ft-lbs of Torque -- more power than competing drive units in this vehicle class
For years, Digga has held its position as the forefront leader in Auger technology. Now, it takes a monumental leap forward with the introduction of the introduction of the HALO Auger Alignment system. This cutting-edge technology revolutionizes drilling and piling operations by giving the operator a visual indicator of their drilling angle, eliminating the need for a spotter, and ensuring all holes drilled are plumb.
The mounting bracket is the connector between the vehicle and the drive unit. Digga manufactures mounting brackets to suit most skid steer loaders, backhoes, tractors, and excavators. Their skid steer mounting brackets feature a slide cradle which allows the user to offset the drive head, allowing for drilling close to structures.
Each mounting bracket is manufactured with high-grade steel and follows the same strict quality control that all in-house Digga equipment adheres to.
The mounts are designed to reduce vibratory frequencies from drilling while allowing pinpoint accuracy for plumb holes, ensuring that this is the smoothest job you've ever had the pleasure of doing.
Digga Hydraulic Hoses w/ Flush-Face Quick Disconnects
Completely manufactured by Digga, using only the highest grade materials and strict quality control, Digga's hydraulic hoses are built for serious professionals with demanding jobs. Hoses will come in 66" or 87" lengths, depending on your machine, with coupler sizes matched to your vehicle.
Also included with this purchase:
- Digga 4DDS High Flow Auger Drive Unit Operating Manual
- Digga 5-Year Gearbox Warranty
- Digga 3-Year Motor Warranty
- Digga 12-Month Manufacturer Warranty
- Attachments King Vehicle Compatibility Guarantee
- BONUS! 30-Day Dedicated 1-on-1 Support for Attachment Install & Use from an Attachments King Expert
Auger Bit Sold Separately
Hoses Sold Separately
Mount & Linkage Sold Separately
If you would like to put together a full Auger Package including a Mount, Hoses, and Auger Bit... give us a call at (302) 732-2804 and we'd be happy to configure one for your machine!
We offer FREE 2-5 day shipping (LTL Freight and Residential) for all Digga attachments. Products will ship out in 1-3 business days and tracking information will be provided. 30-DAY NO HASSLE REFUNDS AND RETURNS If there's an issue with your product, we make refunds and returns quick and easy. To contact us, email sales@attachmentsking.com. More information on refunds and returns can be found here.
